Core Description

The PLX31-EIP-PND is a ProSoft Technology protocol translation gateway featuring bi-directional data bridging between EtherNet/IP and PROFINET IO networks. Fully compatible with multi-vendor control architectures, this stand-alone unit works seamlessly with automated controllers to deliver massive 1440-byte cyclic data capacity and stable industrial network communication.

Configuration

• Rockwell EDS Profile: Simplifies integration into Rockwell Automation PACs using an embedded Electronic Data Sheet Add-On Profile to minimize system development time.
• Subnet Mapping Discovery: Employs the ProSoft Discovery Service utility tool to find the module across the layer-2 network and alter its default IP address without requiring the PC to be on the same subnet.
• Flexible I/O Timing: Permits multiple unique Class 1 I/O connection parameters so field operators can define separate RPI timings for process control streams versus background module health tracking.
• Visual Tutorial Reference: Features an online step-by-step video configuration setup tutorial hosted at psft.com to guide engineers through commissioning.

Ordering Information

Features and Benefits

• Massive Process Data Capacity: Supports huge automation loops by processing up to 1440 bytes of continuous input data and 1440 bytes of continuous output data simultaneously.
• Zero-Code I/O Connections: Eliminates the need to draft tedious controller messaging code or ladder logic instructions when utilizing native EtherNet/IP Class 1 I/O mapping.
• Guaranteed Packet Delivery: Establishes cyclical, deterministic real-time communication pathways that enable the host PAC to instantly monitor for network line faults.
• Multi-Generational Processor Links: Connects legacy Allen-Bradley architectures (like PLC2, PLC5, and SLC) alongside modern ControlLogix and CompactLogix platforms using PCCC and CIP string parsing.
• Disaster Recovery Backup: Protects critical operational parameters via an onboard hardware slot configured to save safety project files onto an optional SD memory card.
