Core Description

The PC56-2K-IDE is a ProSoft Technology in-rack industrial PC module featuring dual-slot hardware expansion via a 40GB IDE drive package. Fully compatible with the ControlLogix backplane, this unit works seamlessly with CLX 55XX processors to deliver high-performance custom application deployment and stable industrial data network communication.

Configuration

• Direct Backplane Data Access: Establishes immediate read and write connectivity straight into the host ControlLogix 55XX processor data tables across the backplane loop without communication routing lag.
• Pre-Installed OS Deployment: Arrives factory-commissioned with your selected Windows embedded operating platform pre-installed directly on the primary internal non-volatile storage media.
• Jumper Safe-State Booting: Features physical hardware jumper headers on the board assembly to trigger an immediate boot into SAFE STATE, instantly restoring default settings during commission crashes.
• Dynamic Database Interfacing: Coordinates with SQL engines, web servers, and local C/C++ runtime scripts using specialized ProSoft development tools to index live processor arrays.

Ordering Information

Features and Benefits

• High-Density Multi-Port Linkage: Equips sub-rack networks with four isolated serial channels to coordinate up to 400 external Modbus devices simultaneously.
• Massive Register Memory Block: Supports extensive field telemetry arrays by allocating an internal data image of up to 10,000 16-bit registers.
• Versatile Serial Signal Interfaces: Provides full interface flexibility on each line, supporting software-selectable RS232, RS422, or RS485 physical hardware tracking.
• Advanced Floating Point Movement: Simplifies data alignment tasks by integrating specialized floating point data handling, including native support for Enron and Daniel configurations.
• RF Modulation Signal Isolation: Protects critical backplane processing elements via 2500 Vrms digital port isolation utilizing high-frequency radio modulation media.
